Instantaneous
- Heats water only when you need it
|
Tankless
|
| Continuous
|
Compact
- Hangs on the wall
- Customized for any need Virtually maintenance free
- Saves valuable space
|
Who would use Paloma Gas or Propane Water Heaters? Click Here
The advanced burner design of the Paloma tankless water heater prevents fowling,
insuring peak output at all times. Burner deterioration is eliminated due to solid
stainless steel construction. Scaling and mineral deposits are prevented by vortex wiping
action and high velocity of water in heat exchanger.
 Model:
- PH-1 2 89,300-30,000 BTU/H Input Modulating burner (automatic output control device)
equipped. Very little minimum operating water pressure required. Recommended for average
home use. AGA design certified. |
 |
Tank System
Wastes precious, costly fuel by keeping the
tankful water constantly heated.
Produces higher fuel bills.
Erratic water temperature in prolonged use ...
hot water turning to warm water turning to cold water.
One or two hour wait for another tankful of hot
water.
|
 |
 |
 |
 |
 |
 |
 Model: PH-6
43,800 BTU/H Input A little, compact heater. Ideal for cottage, cabin, auxiliary
installations such as in office, etc. AGA design certified. |
 Model:PH-24M
178,500-37,700 BTU/H Input Modulating burner (automatic output control device)
equipped. The largest tankless water heater of it's type in the world. Superb
for commercial and industrial use as well as large residential home. AGA design
certified. |
| MODULATING UNITS Turn
on your hot water faucet and water is heated instantly as it flows through the heating
coils. Paloma's burners shut off automatically as soon as you turn off the faucet. The
PALOMA modulating control automatically adjusts the flame to the water flow you select.
SMALL WATER DEMAND... LOW FLAME
LARGE WATER DEMAND... HIGH FLAME
PALOMA produces hot water only
WHEN and AS MUCH AS YOU NEED.
Suitable for residential use.
Just one PALOMA supplies all the hot water you need in your home for shower, bath,
dishwasher, laundry, etc.... *
* heavy simultaneous use may reduce the flow at a particular faucet. |
HIGH TECHNOLOGY AND QUALITY DESIGN Wall-mounted
Paloma tankless water heaters are built to perform efficiently with very little
maintenance. First class materials include a copper heat exchanger and combustion chamber,
brass controls, stainless steel burners, and a hard baked porcelain exterior. Palomas are
easy to service and all parts are easy to replace.
WARRANTY FOR RESIDENTIAL USE
5-year limited warranty on heat exchanger leakage
3-year limited warranty for all other parts.
* Warranty for commercial use, ask Paloma dealer.
|
SAVE MONEY, SPACE AND
ENERGY
Save dramatically on your current water heating bill. Storage-type hot water heaters lose
heat all day long (and all night too!). They consume more energy than any other job in the
home except space heating. Palomas heat only the water you need as you're using it. You
never store hot water again. You never wait for water to heat up again. You never run out
of hot water!
EASY AND QUICK INSTALLATION
Equipped with flexible tubes at Inlet and Outlet points (PH-12M & PH-24M). Install on
wall with just screws securing the bracket
|
|
|
|
|
 |
The graph shows the relation between water flow and
hot water temperature. Wide Temperature
Adjustment: Temp. Rise from 60ºF (WARM) to 100ºF (HOT) at any point.
At "HOT" position, PH-24M will provide 150ºF hot
water from 0.52 gal/min. to 2.8 gal/min.*
You can use at the wide range which is Shown on the graph by
Mixing cold water at faucet.
*When incoming water temperature is 50ºF. |
 PH-6DN/DP, 12M-DN/DP,
24M-DN/DP ARE DESIGN CERTIFIED BY A.G.A.
PH-6DN/DP, 12M-DN/DP, 24M-DN/DP ARE DESIGN CERTIFIED BY C.G.A.
|
|
|
|
|
|
| WARNING:
PROHIBITED INSTALLATIONS. DO NOT INSTALL THE HEATER IN THE FOLLOWING LOCATIONS:
a. In small, poorly ventilated rooms.
b. In air-tight rooms with air-conditioning.
c. Near vents for heating or cooling.
d. In places where chemicals are used.
e. In bathrooms, bedrooms or any occupied rooms normally kept closed.
f. In a location where heater may be exposed to freezing temperatures.
g. In a location where heater is subject to vibration. (such
as Carpet Cleaning, etc.)
h. In Recreational Vehicles, Mobile Homes, Boats and other Watercrafts.
I. As a part of any Circulating Systems. (such as Home Heating, Spa or
Pool Heating, Recirculation to the other Tank, etc.) In corrosive, dusty and greasy
environments.
|
 |
|
|
|
|
|
|
 |
PALOMA FREEZE PROTECTION KIT Thermostatically controlled and keep water control body and water control
case assemblies of heater protected against frozen damage to temperature of approximately
- 40F (without wind-chill factor). (For Model PH-12M & 24M) |
APPLICATIONS:
| The Paloma Portable Water Heater is a must for the serious horseman. This completely self contained unit, mounted on a
dolly, can be easily transported to horse shows, races, or anyplace else hot water is
needed. Simply attach a garden hose for an endless supply of hot water. |
The Paloma tankless water heater is indispensable on farms for cleaning, heating calf water, mixing feed, and in milk
parlors. This safe and economical water heater will pay for itself over and over
again. |
Paloma water heating systems are also being installed by business owners in washrooms,
car wash establishments, restaurants, laundromats, nursing homes, etc. We offer advice on
model selection based on individual need and water flow desired. Paloma, designs and
installs customized water heating systems that will handle virtually any water heating
need. Five heater models are available, up to 178,500 BTU per hour.
Who would use Paloma Gas or Propane Tankless Water Heaters?
| Campgrounds |
Vacation Cottages |
Hot Tubs |
| Roadside Park Restrooms |
Slaughter Houses |
Ready-Mix Cement Plants |
| Fast Food Establishments |
Hotels & Motels |
Apartment Buildings |
| Car Washes |
Commercial & Office Buildings |
Restaurants |
| Solar Backup |
Barber & Beauty Shops |
Nursing Homes |
| Industrial Complexes |
Maintenance Garages |
Carpet Cleaning |
| Industry |
Milk Parlors |
|
| Green Houses & Nurseries |
Residential Homes |
|
 PH24 P (Propane)
|
$1049.00 |
|
PH24 NG
(Natural Gas)
|
$1049.00 |
|
PH12 NG
(Natural Gas)
|
$749.00 |
|
PH12 P (Propane)
|
$749.00 |
|
PH6 NG (Natural Gas)
|
$429.00 |
|
PH6 P (Propane)
|
$429.00 |
|
